| Equipment and Features: "Click on the picture to enlarge it"
Fully Automatic Operation,
User Friendly manual / machine PLC Interface,
Automatic Stock Return to prolong blade life fitted as standard,
Hydraulic powered bow lift & vice,
Dimensions: 1300mm x 1950mm x 1300mm
Weight: 960 Kg
Working Height: 740mm
Blade Size: 3850mm x 27mm x 0.9mm
Coolant, Power Roller Vice,
C / W In-Feed Table: 540mm x 1370mm
(Options: Additional Tables available)
12 Months Parts Only Warrant | Specifications: Capacity @ 0 degrees:-
300mm Round Bar
300mm Square Bar
300mm x 350mm Rectangular Bar
Capacity @ 45 degrees:-
250mm Round Bar
220mm Square Bar
170mm x 250mm Rectangular Bar
Capacity @ 60 degrees:-
100mm Round Bar
100mm Square Bar
100mm x 100mm Rectangular Bar
Motor: 2.2 Kw 1400 rpm
Cutting Speed: 25 - 90 M / Min (inverter)
Swivel Frame Rapid Mitre Facility,
Heavy Duty Construction, |
