Specifications:

Capacity in Round: 700mm
PLC Controlled Auto Angle Setting
Sensitive Pressure
Hydraulic Vice with Hyd.Top Pressure,
Hydraulic Band Tension
with Blade Breakage Detection
Laser Guide Line
Chip Conveyor
Main Motor: 5 Kw 1400 rpm
Cutting Speed: 18 to 75 M/Min.
Blade Size: 8400mm x 54mm x 1.4mm,
Weight: 5500 Kg
Working Height: 850mm
Dimensions: 4100mm x 1750mm x 2720mm

Cutting Capacity:-
0 Degrees
700mm Dia
670mm Square
H630mm x W 1050MM

45 Degrees
700mm Dia.
630mm Square
H 630mm x 700mm

60 Degrees
508mm Dia.
508mm Square
H 450mm x W 600mm
