Hwacheon Hi-Tech 200 A
Cnc Lathe
 |
|
Equipment and Features
Hwacheon Hi-TECH 200B
Description
2007 Hwacheon Hi-TECH 200B 3 Axis slant bed CNC lathe with driven tools C axis, fitted with Fanuc control. tailstock, swarf conveyor, and 8” 3 jaw power chuck. A well-specified and versatile turning centre suitable for a wide range of precision machining applications.
Control
Fanuc Oi-TB CNC Control
Full CNC operation
Tailstock
Tailstock Included: Yes
Accessories
8” 3 Jaw Power Chuck
Tailstock
Swarf Conveyor
Tooling package
Machine Specification
Capacity
Maximum Turning Diameter: 350.5mm
Maximum Turning Length: 398.8mm
Spindle Bore: 76mm
Main Spindle
Maximum Spindle Speed: 3,500 RPM
Spindle Motor Power: 14.9 kW
Turret
Number of Tool Stations: 12
Axis Travels
X Axis Travel: 195.6mm
Z Axis Travel: 429.3mm
POA
