Specifications:

Swing over the Bed: 920mm Dia.
Swing over the Carriage: 745mm Dia.
Max. Turning Dia.550mm (520 VD140 - 512 VD150)
Distance Between Chuck Face & Tail-Stick Centre:
TC 800 = 866mm / TC 1350 = 1416mm
`X` Axis Stroke: 315mm
`Z` Axis Stroke: 800mm or 1350mm
Maximum Speed: 3000 min -1
Spindle Nose: ASA 11" A2
Spindle Bore: 106mm Dia.
Bar Size: 95mm Dia.
Number of Tool positions: STD: 12 / Option: 16,
Number of Driven Stations: 12
Fanuc 30 Series CNC Control

Machine Models can vary in capacity as follows:-
16 Station Turrets
Bar Sizes from 46mm upto 122mm
Spindle Power upto 48 Kw
Driven Tools `C` Axis Option
`Y` Axis Option
17 Kw Driven Tool Power
High Performance Oil Cooled integrated Spindle Motors,
Latest Fanuc 30 Series CNC Control
Hydraulic & Servo Tail-Stock Options
Sub-Spindle Option with 14 Kw Motor
Hydraulic Steady Rest (fixed & servo)
Gantry Loader Option (early 2009)
