| Equipment and Features: "Click on the picture to enlarge it"
Coolant Equipment, 4 Way Tool-Post,
Manual, Low Volt Lighting,
OPTIONS: 3 & 4 Jaw Chucks,
Quick-Change Tool-Post, Steadies,
Centres & Revolving Face-Plates, Taper-Turning,
2 Axis Acu-rite Digital Read-Out System.
TO REQUEST A QUOTATION PLEASE EMAIL OR FAX YOUR NAME & COMPANY DETAILS & THE AJAX MACHINE MODEL NUMBER - THANK YOU | Specifications: Distance Between Centres:
1150mm / 1650mm / 2225mm / 3150mm
Centre Height: 310mm
Swing over the Bed: 620mm Dia.
Swing over the Carriage: 580mm Dia.
Swing over the Cross-Slide: 425mm Dia.
Swing in the Gap: 880mm Dia.
Spindle Nose: ASA B 5.9 No.11
Spindle Bore: 155mm Dia.
Speeds: 16-750 rpm
Main Motor: 7.5 Kw |
