Specifications:

Swing Over the Bed: 550mm Diameter
Max.Machining Diameter; 350mm
Chuck Size: 210mm Diameter
Swing Over the Cross: 350mm Diameter
Max. Turning Length: 410mm
Speed: 4000 rpm
Speed Variation: Randomly
Bar Capacity: 51mm Diameter
Spindle Nose: A2-6
Floor Centre Height: 1065mm
Turret Type: 12 - Angle Variable Arrangement
Travel: `X` 210mm
Travel: `Z` 430mm
Tail-Stock Taper: MT4
