Specifications:

Table Size: 2400mm x 400mm
`X` Travel: 2200mm
`Y` Travel: 400mm
`Z` Travel: 380mm
Rapid Feeds X & Y: 24.000mm/min
Rapid Feed: 5.000mm/min
Work Feed: 5.000mm/min
Tool-Holder: (Size 40 ) ISO 7388
Speed Ranges: 100 to 6,000 rpm
Power to Main Motor: 7.5 Kw
Max. Distance from Spindle to Table: 520mm
Programmable Increments: 0`1 Second
Main Spindle Coolant
Automatic Tool-Changer: 18 Tools
Selection System:Sequential-Bi-Directional
Max.Dia. (adjacent tool) 85mm
Max.Dia. (non adjacent) 135mm
Max.Tool Length: 250mm
Max.Tool Weight: 6 Kg

CNC Control GE Fanuc Series 21-M
